Advanced CAD/CAM Manufacturing at Astec Precision
We have invested in advanced CAD/CAM software to enhance the accuracy, efficiency and complexity of components we can produce.
CAD stands for computer-aided design. We take designs and turn them into digital images so that we can look at how the component will work, also identifying any potential problems with the designs for faster resolution.
CAM is computer-aided manufacturing. It turns the finalised, approved design into tangible products using our sliding head CNC machining services.
This technology represents a significant step forward in our manufacturing capability, enabling us to take on more complex projects across all the industries we serve whilst delivering faster turnaround times for our customers.
Our CAD/CAM system works alongside our sliding head CNC machines to create a streamlined, efficient manufacturing process from initial drawing through to completed production run.
Who We Are
Astec Precision is a UK-based, JOSCAR-approved precision manufacturer serving some of the world’s most demanding industries.
We manufacture complex precision components from the design stage through to production runs of up to one million parts. Our customers work in aerospace, defence, oil and gas, nuclear energy and interconnect sectors, where component quality, accuracy and reliability are non-negotiable.
How Our CAD/CAM Process Works
Our process is designed to reduce risk, improve accuracy and maximise efficiency at every stage of manufacturing.
The customer provides their technical drawing. From this, our engineering team creates detailed 3D models within the CAD/CAM software, defining the manufacturing process and programming the part with precision. Before any physical manufacturing begins, simulations are run to verify that the machining process will perform as intended. This step identifies and resolves potential issues before they reach the production floor, saving time and reducing waste.
Once the simulation is approved, our sliding head CNC machines manufacture the first run of parts. Critically, whilst the machine is running, our engineers use the offline CAD/CAM system to prepare programming for the next components required. This parallel working approach means machines are kept productive and customer projects move forward without unnecessary delays between production runs.
The result is a faster, more efficient process from first drawing to final component.
What We Can Manufacture
Our CAD/CAM capability enhances our capacity to produce complex precision components across a wide range of specifications:
Materials we work with include brass, copper, stainless steel, nickel iron, duplex and exotic alloys. We machine components from 0.2mm to 42mm in diameter, accommodating everything from micro components to standard production parts. Production volumes range from single prototypes through to one million parts, with batch sizes tailored to customer requirements.
Our investment in CAD/CAM technology means we can now manufacture more complex components than ever before, opening up new possibilities for customers with challenging specifications or tight tolerances.
Industries We Serve
Our CAD/CAM precision manufacturing capability supports customers across five critical sectors:
Aerospace manufacturers depend on components that perform reliably under extreme conditions. Our JOSCAR-approved processes and AS9100 certification provide the quality assurance aerospace customers require, whilst our CAD/CAM capability ensures components are produced to exacting tolerances.
Nuclear energy applications require the highest levels of quality control and component integrity. Our processes and certifications support the stringent requirements of nuclear sector customers.
Successful Testing with Circular Backshells
To validate our CAD/CAM process, example tests were performed on circular backshells, electrical connector components used in military, aerospace and interconnect applications. These components require tight tolerances and precise geometry, making them a rigorous test of our CAD/CAM and CNC capability.
The results demonstrated the accuracy and repeatability our process delivers, reinforcing our confidence in offering this capability to customers across all sectors we serve.
The Benefits for Your Business
Our CAD/CAM investment delivers tangible benefits throughout the manufacturing process and across our customer relationship.
Faster project turnaround is achieved through parallel working, with offline programming preparation running alongside active machine production. Customers experience shorter lead times without any compromise on quality or accuracy.
Greater flexibility during prototyping and production means our customers can adapt and refine their components with greater ease. Whether requirements change during the prototyping stage or modifications are needed during a production run, our process accommodates customer demands throughout the product lifecycle.
Increased productivity comes from machines spending more time manufacturing and less time waiting. By completing preparatory work offline, our CNC machines are kept running efficiently, maximising output and reducing cost.
Enhanced accuracy is built into the process from the start. 3D modelling and pre-production simulation mean potential issues are identified and resolved before manufacturing begins, reducing the risk of errors and rework.
Early customer engagement sets our process apart. We work with customers from the earliest stages of a project, building a thorough understanding of requirements and providing engineering input that improves outcomes. This collaborative approach creates stronger working relationships and supports better results from design through to delivery.
From First Drawing to Final Component
Astec Precision supports customers through every stage of the manufacturing journey. From the moment a drawing is received, our team is working to understand your requirements, create accurate models, validate the process and deliver components that meet specification.
Our CAD/CAM capability, combined with our sliding head CNC technology, materials expertise and quality certifications, positions Astec Precision as a capable and committed manufacturing partner for complex precision components across aerospace, defence, oil and gas, nuclear energy and interconnect sectors.
Work With Astec Precision
If you are looking for a UK-based precision manufacturer with the technology, capability and experience to handle complex components across demanding industries, we would welcome the opportunity to discuss your requirements.
From single prototypes to production runs of one million parts, Astec Precision has the capacity, expertise and commitment to deliver.
Contact our team today to discuss your project.
FAQs
CAD stands for computer-aided design. We take designs and turn them into digital images so that we can look at how the component will work, also identifying any potential problems with the designs for faster resolution.
CAM is computer-aided manufacturing. It turns the finalised, approved design into tangible products using our sliding head CNC machining services.
Astec Precision engineering services are built on a wealth of experience and our CAD CAM services save our clients a lot of time and money. We create CAD models and run simulations to optimise your design, whether it’s for a prototype or an item that’s already in production.
The easiest way to get a quote for your design is to submit an enquiry form where you have the option to attach your file to a maximum of 40 MB. You can also send us an email with details about your project and your requirements. Feel free to give us a call too – we’d love to help you as fast as possible.
Our CAD/CAM process creates detailed 3D models from your drawings and runs simulations to validate the machining process before manufacturing begins. This pre-production validation identifies and resolves potential issues before the first part is produced, ensuring components consistently meet specification across prototype and production volumes.
Every component is inspected against specification throughout production, with full traceability maintained from raw material to finished part. Our quality management system is certified to AS9100/EN9100 standards and we are also JOSCAR approved. With many industries demanding the highest standards of safety and reliability, our quality processes are designed to meet those demands in every instance.
Yes. We work with our customers from the earliest stages of a project, providing engineering input on manufacturability, material selection and process optimisation before production begins. This early engagement with our customers is valuable for demanding applications, where specification decisions made at the design stage have a significant impact on component performance and manufacturing feasibility.
